Lighting Equipment Testing

Luminaires mean apparatus which distributes, filters or transforms the light transmitted from one or more lamps and which includes all the parts necessary for supporting, fixing and protecting the lamps, but not the lamps themselves, and where necessary, circuit auxiliaries together with the means for connecting them to the supply. Luminaires are the most common electrical and electronic products in our daily life. They should be designed to ensure safe operation without danger to personnel and the surrounding environment. General requirements and tests of luminaires include classification, marking, mechanical construction, electrical construction, material and photobiological hazards.

Service Content

NOA focus on the compliance and quality of electrical and electronic products, and establish a one-stop service platform for consulting, testing and certification. We provide testing and certification services for lighting equipment.

Product category: Fixed general purpose luminaires, recessed luminaires, portable general purpose luminaires, aquarium luminaires, mains socket-outlet mounted nightlights，luminaires, ground recessed luminaires, portable luminaires for children, floodlights, lighting chains, luminaires for road and street lighting, ballasts for fluorescent lamps, ballasts for discharge lamps.

Relevant Standards

○ GB 7000.1/IEC 60598-1《Luminaires-Part 1:General requirements and tests》

○ GB 7000.4/IEC 60598-2-10《Luminaires-Part 2-10:Particular requirements-Portable Luminaires for children》

○ GB 7000.7/IEC 60598-2-5《Safety requirements for floodlights》

○ GB 7000.9/ IEC 60598-2-20《Luminaires –Part 2-20: Particular requirements – Lighting chains》

○ GB 7000.201/IEC 60598-2-1《Luminaires--Part 2-1:Particular requirements--Fixed general purpose luminaires》

○ GB 7000.202/IEC 60598-2-2《Luminaires-Part 2-2:Particular requirements--Recessed luminaires》

○ GB 7000.203/IEC 60598-2-3《Luminaires-Part 2-3:Particular requirements--Luminaires for road and street lighting》

○ GB 7000.204/IEC 60598-2-4《Luminaires-Part 2-4:Particular requirements--Portable general purpose luminaires》

○ GB 7000.211/IEC 60598-2-11《Luminaires-Part 2-11:Particular requirements-Aquarium luminaires》

○ GB 7000.212/IEC 60598-2-12《Luminaires--Part 2-12:Particular requirements--Mains socket-outlet mounted nightlights》

○ GB 7000.213/IEC 60598-2-13《Luminaires--Part 2-13:Particular requirements--Ground recessed luminaires》

○ GB 19510.1/IEC 61347-1《Lamp controlgear. Part 1:General and safety requirements》

○ GB 19510.4/IEC 61347-2-3《Lamp controlgear-Part 4:Particular requirements for a.c.supplied electronic ballasts for fluorescent lamps》

○ GB 19510.9/IEC 61347-2-8《Lamp controlgear－Part 9: Particular requirements for ballasts for fluorescent lamps》

○ GB 19510.10/IEC 61347-2-9《Lamp controlgear--Part 10:Particular requirements for ballasts for discharge lamps(excluding fluorescent lamps)》

○ GB 19510.13/IEC 61347-2-12《Lamp controlgear--Part 13:Particular requirements for d.c. or a.c. supplied electronic ballasts for discharge lamps(excluding fluorescent lamps)》

○ GB 19510.14/IEC 61347-2-13《Lamp controlgear-Part 14:Particular requirements for d.c. or a.c. supplied electronic controlgear for LED modules》

○ IEC 62471《Photobiological safety of lamps and lamp systems》

○ IEC TR 62778《Application of IEC 62471 for the assessment of blue light hazard to light sources and luminaires》

Service Process

Q&A

The LED light is a lamp. Can it be used as a light source?

A luminaire with integral non-replaceable lamps is regarded as a luminaire. The LED module lamp is an example of a luminaire.

What do the tests of luminaire equipment include in addition to the usual electrical safety test?

Including testing for photobiological hazards, solve the problem of UV and blue light hazards.

What are the classes of luminaire-Protection against electric shock?

Class 0 luminaire: luminaire in which protection against electric shock does rely on basic insulation only. Class I luminaire: luminaire in which protection against electric shock does not rely on basic insulation only, but which includes an additional safety precaution in such a way that means are provided for the connection of accessible conductive parts to the protective (earthing) conductor in the fixed wiring of the installation in such a way that accessible conductive parts cannot become live in the event of a failure of the basic insulation. class II luminaire: luminaire in which protection against electric shock does not rely on basic insulation only, but in which additional safety precautions such as double insulation or reinforced insulation are provided, there being no provision for protective earthing or reliance upon installation conditions. Class III luminaire: luminaire in which protection against electric shock relies on supply at safety extra-low voltage or protective extra-low voltage and in which voltages higher than those of SELV or PELV are not generated.

What is self-ballasted lamp?

Unit which cannot be dismantled without being permanently damaged, provided with a lamp cap and incorporating a light source and any additional elements necessary for starting and stable operation of the light source.

Our Advantage

Authoritative Qualification

NOA has been approved by Certification and Accreditation Administration of the People’s Republic of China（CNCA）(CNCA-R-2002-051), and has obtained qualification of China Inspection Body and Laboratory Mandatory Approval (CMA),and has passed the multiple approvals of China National Accreditation Service for Conformity Assessment (CNAS), International Accreditation Service (IAS), United Kingdom Accreditation Service (UKAS), Joint Accreditation System of Australia and New Zealand (JAS-ANZ). NOA has been approved by State Administration for Market Regulation of China, and has been recognized as inspection and testing institution of China's special equipment, as well as the qualification of China's national equipment supervision and engineering supervision. NOA-DCI is the notified body of the CE directive of the European Commission. NOA has been recognized by the International Electrotechnical Commission (IECQ) by obtaining Electronic Component Quality Assessment System. It is also a national inspection and assessment notified body of import and export commodity in China.NOA is a high-tech enterprise in Shanghai.

Improve Performance, Realize Asset Value Appreciation, and Service Throughout the Entire Value Chain

From pre-design to post-operation, NOA has the ability to guarantee the whole life cycle of the business. NOA, as an independent third-party inspection company, has a large number of domestic and international standards and specifications proficient in design, welding, non-destructive testing, painting, packaging and other fields The experienced team of professional engineers and inspection experts, with more than ten years of experience in the domestic market, is familiar with all aspects of the domestic industrial equipment supply chain, and can provide you with technical support services for the full life cycle of technical services in a timely manner, combining various products. Inspection, certification, testing, consulting, and auditing services can provide you with one-stop all-round comprehensive services.

Quality, Efficiency and Service

NOA has formed a mature and solid operation system in the development of more than 20 years. We let technical experts who are familiar with market regulations and testing standards and have professional industry experience to carry out inspection, evaluation and design review work. While meeting the requirements of domestic and international standards, we ensure that customers can obtain satisfactory service results in the first time with accurate time-sensitive management methods, and ensure that customers can seize the opportunity in the market competition.

Service Area

NOA inspection services currently cover Europe, Australia, Russia, some Middle East regions and most regions in China. NOA can ensure the consistency and continuity of customer service in different regions, and eliminate the impact of unfamiliar environments on customer quality. The guarantees and the impact of project implementation enable customers to participate in different markets across the country or around the world with flawless quality.
